Schmitt Trigger

A Schmitt trigger is a comparator circuit that uses potential triggering and the state is maintained by the input signal potential. It has 2 stable states, but unlike general triggers, it has hysteresis characteristics and can be used for anti-interference. The Schmitt trigger has different threshold voltages for input signals with two different directions of change, negative decreasing and positive increasing.

Packaging method All DIP6
Product Photo Package size(LxWxHmm) Number of Channels Data Transfer Rate (Mbps) Supply Voltage (V) tr (uS) tf (uS) IFO (mA) Topr (Min) (degC) Topr (Max) (degC) Viso (Vrms) File
KLH11L3 KLH11L3 DIP6 7.1x6.48x3.5 1 1 3~16 0.1 5 -55 100 5000 kinglight,kinglight Optoelectronics,kinglight Semiconductor,optocoupler,optocoupler,LED package,LED Display
KLH11L1 KLH11L1 DIP6 7.1x6.48x3.5 1 1 3~16 0.1 0.1 1.6 -55 100 5000 kinglight,kinglight Optoelectronics,kinglight Semiconductor,optocoupler,optocoupler,LED package,LED Display
KLH11L2 KLH11L2 DIP6 7.1x6.48x3.5 1 1 3~16 0.1 0.1 10 -55 100 5000 kinglight,kinglight Optoelectronics,kinglight Semiconductor,optocoupler,optocoupler,LED package,LED Display
