MC1010N-W-M3

Display LEDs/MLED Display

MC1010N-W-M3

    • Suitable for P1.9 semi-outdoor fixed LED displays
    • Entire screen brightness can reach 6000nit+
    • Full flip-chip design for eliminated risk of broken wire caused dead pixel
    • High UV resistant – blue light brightness maintains 93% after 168 hours of UV irradiation
    • Consistent pad and pin designs with common MiP0606 LED for high compatibility and reduced development costs and time

Basic parameters

Version
Product ID Model No. Reference Range Screen
Brightness
(ref)
Color Brightness Brightness
(mcd)
Wavelength
(NM)
Volt(V) Current
(mA)
Typical
value
MIN MAX MIN MAX MIN MAX
S series
MC1010N-W-M3 JT-FCTCMF1010NSURZGQBW-W-M3 R 180 135 240 620 625 1.7 2.4 5 P1.8/32S
6000nit
G 260 200 330 515 535 2.3 3.3 3
B 35 22 50 458 474 2.3 3.3 2

Application scope

Semi-outdoor LED screen Fixed LED Video Wall
