KLT3062

Insulation Voltage：Viso≧5000Vrms
Two types of zero crossing trigger and non-zero crossing trigger
High breakout voltage：400V, 600V and 800V
High critical rise rate of off-state voltage：≧1000V /μs

Download

Sample Request

Home / Optocoupler / Optocoupler / Photo Triac Coupler / KLT3062

Basic parameters

Product	Package	size(LxWxHmm)	VF(V)	VDRM(Max) (V)	VTM(V)	VINH(V)	IT (rms)(mA)	IFT(mA)	Topr (Min) (degC)	Topr (Max) (degC)	Viso (Vrms)
KLT3062	DIP4	6.5x4.58x3.5	1.5	600	3.0	20	70	10	-55	+100	5000

Benchmarking model

Broadcom/Avago	Onsemi/Fairchild	Toshiba	Vishay	Liteon	EL	Cosmo	Sharp	QUNXIN
		TLP361J/TLP363J			ELT3062		PC3SH21YFZ	QX562

Application scope

AC Motor Drivers AC Motor Starters Static Power Switches Lighting Controls Solenoid/Valve Controls Solid State Relays Temperature Controls Industrial Controls Home Appliances
