KL852

Photo Darlington

KL852

    • Low input forward current
    • High current transfer ratio
    • DC and AC inputs
    • Level shifting
    • High input-output isolation voltage and high collector-emitter voltage
KL852KL852Download KL852KL852Sample Request
Home / Optocoupler / Optocoupler / Photo Darlington / KL852

Basic parameters

Product Package size(LxWxHmm) VF (V) BV CEO (Min) (V) V CE(SAT) (Max) (V) IF (mA) CTR (%) tr (uS) tf (uS) ton (uS) toff (uS) Topr (Min) (degC) Topr (Max) (degC) Viso (Vrms)
KL852 DIP4 6.5x4.59x3.5 1.2 350 1.2 1 1000~15000 300 100 - - -55 100 5000

Benchmarking model

Broadcom/Avago Onsemi/Fairchild Toshiba Vishay Liteon EL Cosmo Sharp QUNXIN
FOD852 TLP627 SFH619A LTV-852 EL852 PC852 QX852

Application scope

Household Power Supplies Switching Circuits Connectors Solenoid Valve Controls Telephone AC Motor Drivers Temperature Control Signal Transmitters

Product specifications
