KL851

Photo Transistor

KL851

    • Provides isolated feedback
    • Interface between logic circuits
    • Highly reliable transistor output optocoupler with base pins
    • Level shifted
    • DC and AC inputs
KL851KL851Download KL851KL851Sample Request
Home / Optocoupler / Optocoupler / Photo Transistor / KL851

Basic parameters

Product Package size(LxWxHmm) VF (V) BV CEO (Min) (V) V CE(SAT) (Max) (V) IF (mA) CTR (%) tr (uS) tf (uS) ton (uS) toff (uS) Topr (Min) (degC) Topr (Max) (degC) Viso (Vrms)
KL851 DIP4 6.5x4.59x3.5 1.2 350 0.4 5 50~600 4 5 -55 110 5000

Benchmarking model

Broadcom/Avago Onsemi/Fairchild Toshiba Vishay Liteon EL Cosmo Sharp QUNXIN
TLP628M SFH614A PS2513-1 PS2513L-1 LTV-851 EL851 KP1210 PC851 QX851

Application scope

Household Power Supplies Switching Circuits Connectors Solenoid Valve Controls Telephone AC Motor Drivers Temperature Control Signal Transmitters
