KL3H7

Photo Transistor Coupler

KL3H7

    • Provides isolated feedback
    • Interface between logic circuits
    • Provides 1-channel and 5-channel
    • Level shifting
    • DC and AC inputs
    • Regulated feedback circuitry in SMPS
    • Eliminates ground loops
KL3H7KL3H7Download KL3H7KL3H7Sample Request
Home / Optocoupler / Optocoupler / Photo Transistor Coupler / KL3H7

Basic parameters

Product Package size(LxWxHmm) VF (V) BV CEO (Min) (V) V CE(SAT) (Max) (V) IF (mA) CTR (%) tr (uS) tf (uS) ton (uS) toff (uS) Topr (Min) (degC) Topr (Max) (degC) Viso (Vrms)
KL3H7 SSOP4 4.4x2.70x2.0 1.2 80 0.2 5 50~600 5 3 - - -55 +110 3750

Benchmarking model

Broadcom/Avago Onsemi/Fairchild Toshiba Vishay Liteon EL Cosmo Sharp QUNXIN
ACPL-217 FODM217/HMHA281/HMHA2801 TLP281/TLP285/TLP291/TLP293 VOS615A/VOS617A/VOS618A/TCMT110x LTV-217 EL3H7 KPS2801 PC3H2/PC3H3/PC3H7/PCHU7 QX3H7

Application scope

Household Power Supplies Switching Circuits Connectors Solenoid Valve Controls Telephone AC Motor Drivers Temperature Control Signal Transmitters

Product specifications

Tags： KL3H7    Photo Transistor Coupler
