KL354N

Photo Transistor Coupler

KL354N

    • Provides isolated feedback
    • Interface between logic circuits
    • Provides 1-channel and 4-channel
    • Level shifting
    • DC and AC inputs
    • High collector-emitter voltage (VCEO = 80V)
    • Eliminates ground loops
KL354NKL354NDownload KL354NKL354NSample Request
Home / Optocoupler / Optocoupler / Photo Transistor Coupler / KL354N

Basic parameters

Product Package size(LxWxHmm) VF (V) BV CEO (Min) (V) V CE(SAT) (Max) (V) IF (mA) CTR (%) tr (uS) tf (uS) ton (uS) toff (uS) Topr (Min) (degC) Topr (Max) (degC) Viso (Vrms)
KL354N SOP4 4.4x4.1x2.0 1.2 80 0.2 ±1 20~300 18 18 - - -55 +100 3750

Benchmarking model

Broadcom/Avago Onsemi/Fairchild Toshiba Vishay Liteon EL Cosmo Sharp QUNXIN
ACPL-354 FODM2705 TLP120/TLP124/TLP126/TLP180/TLP182/TLP184 SFH691AT EL354N LTV354T PC354/PC364

Application scope

Household Power Supplies Switching Circuits Connectors Solenoid Valve Controls Telephone AC Motor Drivers Temperature Control Signal Transmitters

Product specifications

Tags： KL354N    Photo Transistor Coupler
